How do you change the belt on a Kenmore canister vaccum Whispertone 12.0, model number 116 5561190 and Serial number DE3604428 Debra A Clark January 2006 Kenmore Household Appliances, Vacuum Cleaners Model Number 116 Hi Debra, The answer lies under the "Power-Mate" light cover. Press the sides of the cover in and lift off the light cover.
Full Answer
How do you replace a Kenmore power-mate vacuum belt?
Although Kenmore does not specify a replacement interval for the Power-Mate belt, most manufacturers recommended replacing a vacuum belt every six months. Turn off the power switch on the canister, and unplug the power cord from the wall outlet. Flip the suction head over and remove the two screws. There is a screw on each side, near the wheels.
What is an agitator belt on a Kenmore vacuum?
A belt wraps around the shaft on the vacuum’s suction motor and around the brush. When you turn on the vacuum, the motor rotates, turning the brush belt and rotating the brush. When your Kenmore vacuum begins to leave dirt behind, changing the agitator brush belt can restore the vacuum’s ability to clean your floors.
How do you fix a Kenmore vacuum that is leaving dirt?
When your Kenmore vacuum begins to leave dirt behind, changing the agitator brush belt can restore the vacuum’s ability to clean your floors. Unplug the power cord on your canister-style Kenmore vacuum cleaner from the wall outlet.
How do you replace the agitator on a Kenmore washing machine?
Wrap the other side around the motor shaft. Mount the agitator assembly back into the suction head. Replace the cover, flip down the latches on the rear and tighten the screws on the bottom. Kenmore recommends you clean the agitator assembly when replacing the belt. To clean the agitator belt, pull off the debris wrapped around it.
How do you change a belt on a Kenmore canister vacuum?
0:342:40Tutorial: Kenmore Canister Vacuum Cleaner Belt Change - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd then what you want to do is go ahead and push her that button to make the the end of the vacuumMoreAnd then what you want to do is go ahead and push her that button to make the the end of the vacuum go down. And then you can get the top off because the quick release gets in the way.
How do you change a Sears vacuum belt?
0:293:51How to Replace a Vacuum Belt - YouTubeYouTubeStart of suggested clipEnd of suggested clipRight this Center here I'm just going to press down and pull out at the same. Time. Just like thatMoreRight this Center here I'm just going to press down and pull out at the same. Time. Just like that now this piece will come right off the vacuum to replace the belt I have to remove the brush.
How do you open a Kenmore Progressive vacuum?
0:073:04How To Change A Canister Vacuum Bag - YouTubeYouTubeStart of suggested clipEnd of suggested clipTo do this i'll depress the tab on the hose. Latch then while a tab is depressed i'll pull straightMoreTo do this i'll depress the tab on the hose. Latch then while a tab is depressed i'll pull straight up on the suction hose to remove.
How do I remove the roller from my Kenmore vacuum?
0:372:52How to Replace the Brush Roll on an Upright Vacuum - YouTubeYouTubeStart of suggested clipEnd of suggested clipOkay with the screws removed. Now I can lift this plate right off of the vacuum. And you can see nowMoreOkay with the screws removed. Now I can lift this plate right off of the vacuum. And you can see now we have access to the roller. Itself. Now I'll go ahead and remove the roller from the machine.
How do you know if you need a new vacuum belt?
How Can I Tell if it's Time to Change My Vacuum Cleaner Belt?Your Vacuum Has Suddenly Gotten Extra Noisy. ... Your Suction Power has Slipped. ... Your Vacuum Cleaner is Leaving a Trail. ... Conclusion.
Are all vacuum belts the same?
The major types of vacuum belts are determined by their different shapes. As vacuum designs have improved over the years, new belt shapes have been developed to increase both their durability and their ability to transfer power from the vacuum's motor.
How is change a Kenmore canister vacuum bag?
0:030:54How To Replace Your Dust Bag - YouTubeYouTubeStart of suggested clipEnd of suggested clipRed bag mount down and install bag into slots pushing down until the cardboard tab locks intoMoreRed bag mount down and install bag into slots pushing down until the cardboard tab locks into position and the holes align tuck. The back securely into the bag cavity.
How do you change a Kenmore canister bag?
0:051:24How to Change SuperVAC Bags for Kenmore Type U/L/O Model 5068 ...YouTubeStart of suggested clipEnd of suggested clipPull the old vacuum bag out of the vacuum. And throw it away remove a new vacuum bag from theMorePull the old vacuum bag out of the vacuum. And throw it away remove a new vacuum bag from the protective plastic wrap. Next take a new vacuum bag. And fold the cardboard.
How do I find my Kenmore vacuum model number?
0:241:28Vacuum Model Number Identification - YouTubeYouTubeStart of suggested clipEnd of suggested clipThe base near the rear wheels. For canister vacuums the label can often be found on the outside ofMoreThe base near the rear wheels. For canister vacuums the label can often be found on the outside of the main housing. Or on the inside for central vacuum systems you may find two model number labels.
Why is the brush not spinning on my vacuum?
Vacuum Cleaner: Why doesn't my vacuum cleaner's brush roll spin? A broken drive belt, damaged brush roll, jammed brush roll bearings, tripped brush roll motor overload, failed brush roll motor or a wiring failure in the wand or nozzle can prevent the brush roll from spinning.
How do I remove the brush roller from my vacuum?
0:001:26How To Clean the Brush Roll on ANY Vacuum FAST - Remove Hair etc.YouTubeStart of suggested clipEnd of suggested clipThing heavy amount you can use a razor blade for example if you don't really mind getting that youMoreThing heavy amount you can use a razor blade for example if you don't really mind getting that you make sure you don't want to cut the bristles or anything.
How do you fix the brush roll on a vacuum?
0:572:11What to do if the Brush Roll Won't Rotate on your BISSELL® Pet Hair ...YouTubeStart of suggested clipEnd of suggested clipPull the roller straight out and slide the belt off the motor gear. Inspect the brushroll by puttingMorePull the roller straight out and slide the belt off the motor gear. Inspect the brushroll by putting it on its end and spinning it it should spin freely.
How do you change the belt on a Hoover Rewind vacuum?
1:002:46Hoover Elite Rewind Belt & Roller Replacement - YouTubeYouTubeStart of suggested clipEnd of suggested clipAnd you're gonna slide it in hook the belt right on those grooves. And just place it in and you'reMoreAnd you're gonna slide it in hook the belt right on those grooves. And just place it in and you're gonna take this end. And snap it into place Christian.
Why does my belt keep coming off my vacuum cleaner?
With debris wrapped around the roller brush, a dirty vacuum cleaner powerhead can stop the roller from turning while the belt still spins away. The friction can cause the belt to burn and break. Running over things in our home that causes the roller brush to stop spinning can also cause the belt to burn.
How do you check a vacuum belt?
0:161:28How to Check the Belt and Brush Roll on Your CleanView® Vacuum ...YouTubeStart of suggested clipEnd of suggested clipUp use the screwdriver to take out the six screws on the bottom. Cover. And lift the brushrollMoreUp use the screwdriver to take out the six screws on the bottom. Cover. And lift the brushroll straight out and remove from belt clean debris from the brush roll. Place it on its side and spin.
How do you change the belt on a Hoover windtunnel T Series?
0:051:31Hoover T-Series Bagged Upright Replacing the Belt ... - YouTubeYouTubeStart of suggested clipEnd of suggested clipSlide the new belt through the guide. And over the motor shaft. Then over the space on the brushrollMoreSlide the new belt through the guide. And over the motor shaft. Then over the space on the brushroll where there are no bristles. With the belt in place pull.
Step 1
Turn off the power switch on the canister, and unplug the power cord from the wall outlet.
Step 2
Flip the suction head over and remove the two screws. There is a screw on each side, near the wheels.
Step 3
Turn the suction head right-side up. Press the adjustment button on the back to lower the handle. Flip up the latches on the rear of the suction head.
Step 4
Grab both sides of the suction head, push inward and carefully pull off the cover. Lift the agitator assembly from the suction head and remove the old belt.
Step 5
Route the new belt around the agitator assembly. Wrap the other side around the motor shaft. Mount the agitator assembly back into the suction head.
Step 6
Replace the cover, flip down the latches on the rear and tighten the screws on the bottom.
How to remove old belt from motor?
Pull the belt off the shaft of the motor. Lift the agitator bar and slide the belt off its end to remove the old belt.
How to reinstall agitator bar?
Line up the square extensions on the ends of the agitator bar with the slots on the vacuum and push the agitator bar down to reinstall it.
Why won't my Kenmore upright vacuum spin?
If the agitator bar does not spin when your Kenmore Progressive upright vacuum cleaner is turned on, you have a broken or stretched belt. The vacuum's belt turns the agitator bar to clean your carpets. A broken or stretched belt won't turn the bar, making your vacuum cleaner useless. This is a common repair that you can do at home in a matter ...
Can a broken vacuum belt turn the bar?
A broken or stretched belt won't turn the bar, making your vacuum cleaner useless. This is a common repair that you can do at home in a matter of minutes. Purchase a UB-1 belt and replace the old belt to repair your vacuum.
Who is Amy Kingston?
Amy Kingston has been a professional writer since 2001. She has written articles for various publications, including "Health" magazine, "Jackson Parenting" magazine, the "Bolivar Bulletin" newspaper and "A Musician's Pursuit." Kingston was also published in "Voices of Bipolar Disorder."
How to change agitator brush belt?
Grab the agitator brush with your hands. Lift the brush from the power head to release the tension on the agitator brush belt. Slide the belt from the left side of the brush. Pull the belt from the motor shaft near the rear of the power head. 8. Slide the replacement agitator brush belt over the end of the brush.
How to pull agitator brush?
Grab the left side of the agitator brush and pull it from the base. Slip the belt from the left side of the brush. Pull the belt from the motor shaft near the rear of the vacuum head.
How to use a Kenmore canister vacuum?
Canister Vacuum. 1. Unplug the power cord on your canister-style Kenmore vacuum cleaner from the wall outlet. 2. Move the telescoping wand attached to the vacuum power head until it becomes perpendicular to the floor. Press the quick-release pedal on top of the power head to the left side of the wand.
How does a Kenmore vacuum work?
When you turn on the vacuum, the motor rotates, turning the brush belt and rotating the brush. When your Kenmore vacuum begins to leave dirt behind , changing the agitator brush belt can restore the vacuum’s ability to clean your floors.
What is a Kenmore upright vacuum?
By Cecilia Harsch. Kenmore manufactures canister and upright vacuums to clean both your carpeted and hard floor surfaces. Each style of vacuum uses an agitator brush to beat the surface of the floor to loosen the dirt and allow the vacuum to capture the dirt in a vacuum bag. A belt wraps around the shaft on the vacuum’s suction motor and around ...
How to put tabs on a vacuum?
Line up the tabs on the vacuum base with the slots along the front bottom of the vacuum head. Push the base against the bottom of the vacuum until you hear the locking tabs snap in place. Slide the two tabs behind the long roller toward the right and left sides of the vacuum.
How to get the agitator brush out of a vacuum?
Look for the long roller directly behind the agitator brush. Find the two tabs directly behind the long roller. Use your fingers to push the tabs toward the center of the vacuum.
How many parts does a Kenmore vacuum need to be disassembled?
Before we start off with our disassembly, it’s necessary to know that we need to take apart 3 parts of the Kenmore manual vacuum cleaner.
Which Kenmore vacuum is easy to clean?
One such product is the Kenmore Vacuum model 116 which has an easy to clean feature and comes in an affordable price tag as well.
Why is my vacuum bag red?
1. Whenever the vacuum’s dirtbag is filled up or clogged, the indicator will turn red to alert the user. Just replace the bag with a new one!
What happens if your vacuum belt breaks?
3. A broken belt might result in improper dirt removal or weak vacuum suction. Belt replacement is the smart move rather than fixing it.
Why is my dust bag clogged?
1. The dirtbag or the dust tube might be clogged due to too much dirt accumulation. An easy solution is to replace the dust bag or clean the tube thoroughly.
How to use a magic wand?
The first and foremost thing to do is to press all the release buttons starting from the top to the base of the wand. Once you’ve pressed the buttons, you have to work your way through the wand by twisting and pulling each part.
How many sections are there in a wand?
This will result in 3 discrete sections of the wand- the upper wand, the middle section, and the footplate. After this is done, put these pieces away in a safer place to move on to the next stage.
How to remove brush roller assembly?
Turn the brush roller assembly upside down and remove the 3 screws that secure the cover. Turn the brush roller assembly upright and remove the cover.
What is a ribbed drive belt on a canister vacuum?
By Lyle Weischwill. Some canister vacuums have a ribbed drive belt that spins the brush roll on a power brush attachment. If the brush roll slips, you can replace it using these instructions. Repair difficulty. Time required.
What does a suction motor do?
The suction motor on a vacuum creates the draw of air at the cleaning head that picks up dirt. If the vacuum won't run, give it a new life by replacing the suction motor. These steps explain how. Repair difficulty. Time required.
Is it dangerous to repair an appliance?
Warning: Undertaking repairs to appliances can be hazardous. Use the proper tools and safety equipment noted in the guide and follow all instructions. Do not proceed until you are confident that you understand all of the steps and are capable of completing the repair. Some repairs should only be performed by a qualified technician.
How to replace drive belt on Kenmore 116?
To replace the drive belt as on my Kenmore model 116 (others may be different), remove the cover (slide two latchs outward) and the light/agitator cover (release the small loops attached to the rubber 'bumper' edges, then pinch two clips at back of cover and lift up from the back, rotating it forward). Pull the rubber 'bumper' edges away from the ends of the roller, lift the roller straight up, and the pieces that hold the roller at either end will slide up in their slots. It is difficult to see this until the roller is lifted. Notice that the piece that is in each slot has the flat edge up, as they should be reinserted with this orientation. Fully remove the roller. Note that the belt placement order can be reversed (roller then drive axle), but there are some tight spaces and fairly sharp edges next to the path of the belt. With the agitator selector lever in the "Carpet" position (engaged/forward), place the good belt around the drive axle and also around the movable selector roller towards the rear of the housing. Stretch the belt to position it on the roller, then pull the roller forward to line up and insert the end pieces into the slots. This will likely be a hard stretch of the belt, and the entire housing unit will need held in place to make this stretch. Check that the belt is turning freely and is correctly lined up on the roller and the drive axle. This belt replacement can be achieved with two good hands and likely a foot or two to hold the housing, but additional hands should be very helpful. I sincerely pray for your patience and your fingers when making this belt change.
How to remove cover on Kenmore 116?
to release the cover on a kenmore 116 3493593C there are two screws on the bottom that need to be removed and then pry the two tabs at the back of the powerhead out and then use the screwdriver to pry the two sides out where it says "insert screwdriver to separate and it comes apart. Fairly easy when you know. Really hard when you don't;.
How to remove a vacuum head?
(2) Remove the two then-exposed screws. (3) Remove the small plastic lever you usually use to release the vacuum head from the steel tube by pulling up and then out. (4) Turn the housing over. (5) Using your flat-head screwdriver (two -- one on each side -- is even better because you can keep the first side released while you work on the second), release the tension on the two plastic tabs on either side of the head. The location of these tabs is written on your rubber bumper, but you have to look hard to see the writing. (6) Pry the two halves apart. They should come apart easily.
Is it necessary to remove the rubber bumper?
NOTE: IT IS NOT NECESSARY TO REMOVE THE RUBBER BUMPER TO DO ALL OF THIS STUFF. But if you are reading this, you may already have done that. Just remember to put it back on before putting the two halves together again.
