How to Use a Triangle Scale Ruler
- Step 1. Unroll the blueprint on the surface of the worktable.
- Step 2. Determine the scale of the blue print. The scale will be located in the lower right-hand corner of each blue...
- Step 3. Flip the architects rule around until you find the side of the rule that reads 1/4. If your triangle scale rule...
What are the steps of using a ruler?
The steps we follow are:
- Place the ruler on empty paper and take a divider and keep on starting point at zero (0) and widen the divider up to the length of 4.5 cm.
- Now, lift both the arms of the divider carefully, and place them on empty paper, and mark both the arcs with a pencil.
- Next, join both the points and name as A and B. We get a 4.5 cm length of line segment AB.
How many angles can we make using ruler and compass?
There is no way to construct such an angle using a compass and a ruler. That's why they invented the protractor.
How to use an architectural or scale ruler?
Things You'll Need
- Scale ruler (s)
- Architectural drawing
- Calculator
- Drafting paper
- Mechanical pencil
- Drafting pen
How to use a scale ruler on our worksheet?
Use the horizontal and vertical ruler to measure items in the worksheet (such as column width, row height, or the width and height of pages). Click File > Options > Advanced. Under Display, in the Ruler units box, click the units that you want to use.
How do you use a metric ruler?
0:496:06How to Read a Metric Ruler - YouTubeYouTubeStart of suggested clipEnd of suggested clipYou see how easily I went from millimeters to centimeters I just divided by 10 by sliding theMoreYou see how easily I went from millimeters to centimeters I just divided by 10 by sliding the decimal place over. Like.
How does a metric scale work?
0:5411:05How to Read a Metric Scale - YouTubeYouTubeStart of suggested clipEnd of suggested clipThe right number is what is used to build the item that you're going to build so one centimeter onMoreThe right number is what is used to build the item that you're going to build so one centimeter on your drawing is equal to 50 centimeters of the real item and so that's equivalent to a half a meter.
How does a triangular scale work?
On a triangular scale, you'll most likely find two rows of numbers on each edge, one above the other. If your scale has 1/4 at one end of an edge and 1/8 at the other end, the row of numbers that starts with zero closer to the 1/4 are the numbers that correspond to that scale, with a 1/4 inch corresponding to one foot.
What is triangular metric scale?
A triangular metric scale is similar to the architectural scale in that it has six edges, but it has only one scale ratio per edge. The ratio is marked at the left end of the scale. For example, the scale of 1:50 means that 1 mm on the drawing represents 50 mm on the object.
How do you draw a metric scale?
1:4812:03How To Make A Scale Drawing - A Tutorial - YouTubeYouTubeStart of suggested clipEnd of suggested clipActual size if you're working in metric. You may find that the best ratio would be 1/10. Actual sizeMoreActual size if you're working in metric. You may find that the best ratio would be 1/10. Actual size one centimeter equals 10 centimeters on the final drawing.
How do you calculate a metric scale?
To convert a scaled measurement up to the actual measurement, simply multiply the smaller measurement by the scale factor. For example, if the scale factor is 1:8 and the smaller length is 4, multiply 4 × 8 = 32 to convert it to the larger actual size.
How do you use a triangle?
0:113:40Manual Drafting: Equally Spaced, Parallel Angled Lines - YouTubeYouTubeStart of suggested clipEnd of suggested clipThat are parallel to a line that is drawn at a random angle a way to do that is by positioning twoMoreThat are parallel to a line that is drawn at a random angle a way to do that is by positioning two triangles and using one triangle as the base for moving the other.
Where is the inch in triangular scale?
The first side has an inch scale, divided to 1/16" and numbered by ones from 1 to 6, along one edge. The other edge has scales for 3/32" and 3/16" to the foot. Between these scales is a scale divided to 3/32", numbered from left to right by fours from 0 to 60 and from right to left by twos from 0 to 28.
What do you call a triangular ruler?
A triangle ruler is called a 'set square. ' They are triangular-shaped and sometimes have a cut-out center.
What is metric ruler?
A metric ruler is the standard instrument for measurement in the scientific laboratory. On a metric ruler, each individual line represents a millimeter (mm). The numbers on the ruler represent centimeters (cm). There are 10 millimeters for each centimeter. To read a metric ruler, each individual line represents .
What are the examples of metric scale?
Metric Units Length: Millimeter (mm), Decimeter (dm), Centimeter (cm), Meter (m), and Kilometer (km) are used to measure how long or wide or tall an object is. Examples include measuring the thickness or length of a debit card, length of cloth, or distance between two cities.
How do you do 1 100 on the metric scale?
A scale of 1 to 100 is indicated on a drawing using the code 1:100. This can be interpreted as follows: 1 centimetre (0.01 metre) measured with a ruler on the plan would need to be multiplied by 100 to give the actual size of 1 metre.
How do you read a mm scale?
Locate the zero end of the ruler, and then count each individual mark along the edge of the ruler. Each mark represents 1 millimeter or mm, so counting five marks is the same as counting 5 millimeters, counting 10 marks is the same as counting 10 millimeters and so on.
A Scale What?
When you start architecture school you will hear people talk about scale and scale rulers. Most of the time they will assume you know what this is and won’t tell you how to use an architectural scale ruler.
What Is Scale?
Scale in design refers to the enlarged or reduced representation of a real, full-size object in a drawing or physical model while retaining the proportions of the original. In architecture, we generally reduce the scale rather than enlarge it. A scale drawing or model is like taking the original and shrinking it down proportionally.
Choosing A Scale Ruler
A scale ruler is used to help understand the proportions of the drawing or model representation as a proportion of the real-life object.
Using A Scale Ruler
Once you have the correct scale ruler, how do you use it? There are two ways to use a scale ruler:
Representing Scale
Before we start a drawing we must choose our scale and use it consistently. We must also clearly indicate the scale on the drawing so our viewer knows how to measure. There are three ways to represent a scale on a drawing.
Converting Between Scales
One of the trickiest things is converting between scales. For example, you may be asked to convert a 1:500 site plan to a 1:100 floor plan, or a 1:100 elevation to a 1:10 detail. Sometimes the maths is easy enough.
What Next?
CAD software programs are great, and while you are designing and documenting you may come to rely on these a lot. This means you will be thinking at a scale of 1:1.
A Scale What?
What Is Scale?
- Scalein design refers to the enlarged or reduced representation of a real, full-size object in a drawing or physical model while retaining the proportions of the original. In architecture, we generally reduce the scale rather than enlarge it. A scale drawing or model is like taking the original and shrinking it down proportionally. We can either work in metric (metres, centimetres, …
Types of Scale
- Certain scales are used to produce different drawings. These include: Learn more in the article titled “An Introduction To Architectural Drawing Systems”
Choosing A Scale Ruler
- A scale ruleris used to help understand the proportions of the drawing or model representation as a proportion of the real-life object. The first thing you must consider in choosing a scale ruler is which type of unit of measurements you are using. This will vary depending on which country you reside in. 1. Imperial Units – Refer to feet and inches...
Using A Scale Ruler
- Once you have the correct scale ruler, how do you use it? There are two ways to use a scale ruler: 1. Converting measurements from real life to a scale drawing; and 2. Converting measurements on a scale drawing to real life.
Representing Scale
- Before we start a drawing we must choose our scale and use it consistently. We must also clearly indicate the scale on the drawing so our viewer knows how to measure. There are three ways to represent a scale on a drawing. 1. Human Body– Showing a human body on a drawing immediately gives the reader an indication of the scale. This is more commonly used in the conc…
Converting Between Scales
- One of the trickiest things is converting between scales. For example, you may be asked to convert a 1:500 site plan to a 1:100 floor plan, or a 1:100 elevation to a 1:10 detail. Sometimes the maths is easy enough. If not, I have created a simple “Drawing Scale Conversion Sheet” that allows you to simply and easily convert between scales. Most of the time, you should be able to …
What Next?
- CAD software programs are great, and while you are designing and documenting you may come to rely on these a lot. This means you will be thinking at a scale of 1:1. However, the minute your drawings are printed to scale on a page, you need to be able to read and interpret them. You will also need to be able to use a scale ruler when sitting face-to-face with anyone to develop conce…
