What does IMC mean on Conduit?
To specify, IMC include the following: Intermediate Metal Conduit (IMC) conduit and elbows shall be equal to that manufactured by Allied Tube & Conduit Corporation. IMC shall be hot galvanized steel O.D. with an organic corrosion resistant I.D. coating and shall be Listed to UL Safety Standard 1242 and manufactured in accordance with ANSI C80.6.
What type of threads are used in Allied IMC?
Allied IMC uses the same threaded couplings and fittings as RIGID conduit, and the 3/4″ NPT threads (ANSI B1.20.1) are also full cut and galvanized after cutting. Color-coded end-cap thread protectors keep the threads clean and sharp, and also help to provide instant trade size recognition.
Which couplings for threaded rigid conduit and IMC iron pull elbows?
Split Couplings for Threaded Rigid Conduit and IMC Malleable Iron Pull Elbows Offset Chase Nipples Compression Rigid Couplings for Threadless Rigid Conduit
What is the length of IMC wire?
It is sold in 10-foot lengths, with or without threaded ends. Originally introduced by Allied Tube & Conduit Corporation, IMC is manufactured in accordance with UL (formerly Underwriters Laboratories) safety standard 1242 and ANSI C80.6. The National Electrical Code (NEC) includes a specific article detailing the proper use of IMC, Article 342 .
What type of conduit is threaded?
Rigid Metal Conduit—RMC and IMC Rigid metal conduit, or RMC, is heavy-duty galvanized steel tubing that is installed with threaded fittings.
What is the difference between IMC and EMT conduit?
Examples of rigid metallic raceways are: Electrical metallic tubing (EMT): Lightweight and easy to install. Intermediate metallic conduit (IMC): Has a thicker, galvanized wall, making it suitable for outdoor applications.
Is IMT threaded?
EMT is never threaded and is not designed for strong connections like IMC and RMC. In residential wiring, IMC is usually limited to service entrance assemblies and exposed runs to and from exterior service panels.
What does IMC mean in conduit?
Intermediate Metal ConduitIntermediate Metal Conduit (IMC) provides a lighter weight, lower-cost solution for jobs that require the same strength as galvanized rigid steel conduit.
Is EMT conduit threaded?
You don't thread EMT or FEMT, which means saving a series of steps when running this type of raceway. You can bend EMT on a conduit bender, but make sure the shoe says EMT on it.
Can you bend IMC?
Rigid and IMC conduit are the hardest raceways to bend because they have a much thicker and harder wall. ½” and ¾” rigid or IMC can be bent by hand using a hickey (or segment bender).
What's the difference between IMC and rigid?
Intermediate metal conduit (IMC) is a thinner-walled rigid metal conduit that is satisfactory for uses in all locations where rigid metal conduit is permitted to be used. Also, threaded fittings, couplings, connectors, and so on, are interchangeable for either IMC or rigid metal conduit (RMC).
What is the difference between IMC and GRC?
IMC is covered in Article 342 and is a steel galvanized conduit just like GRC, but it is made of a different type of steel with a thinner wall thickness. The wording in Article 342 and Article 344 is identical; therefore, both products are permitted in exactly the same installation applications.
Is IMC conduit bendable?
Features & Specifications Allied IMC is resistant to impact and is easy to cut, bend and join for smooth, continuous raceways.
Can IMC conduit be in concrete?
IMC can be installed in concrete, in direct contact with the earth, or in areas subject to severe corrosive influences where protected by corrosion protection and judged suitable for the condition. Just like rigid steel conduit.
How much does IMC conduit cost?
IMC CONDUIT PRICE LISTTEM NODESCRIPTIONPRICE1IMC Conduit Pipe312.002IMC Conduit Pipe424.003IMC Conduit Pipe609.004IMC Conduit Pipe825.006 more rows•May 1, 2020
What are the maximum number of bends allowed for IMC?
The maximum that is permitted is not more than 360° in bends between pull points. All rough edges must be removed when the conduit is cut.
What is EMT conduit?
Steel conduit and electrical metallic tubing (EMT) refers to the steel-based durable enclosures that route individual electrical wiring conductors in a building or structure and protect the wires from impact, moisture, and chemical vapors.
What is the difference between IMC and rigid conduit?
Intermediate metal conduit (IMC) is a thinner-walled rigid metal conduit that is satisfactory for uses in all locations where rigid metal conduit is permitted to be used. Also, threaded fittings, couplings, connectors, and so on, are interchangeable for either IMC or rigid metal conduit (RMC).
What is the difference between IMC and GRC?
IMC is covered in Article 342 and is a steel galvanized conduit just like GRC, but it is made of a different type of steel with a thinner wall thickness. The wording in Article 342 and Article 344 is identical; therefore, both products are permitted in exactly the same installation applications.
How strong is IMC conduit?
UL 1242 IMC standard includes more performance-based requirements than the rigid steel conduit standard, including a beam strength test and a threaded conduit pullout test....IMC: Just the Facts.RMCIMCTensile Strength55,00062,000Yield Strength35,00055,000
What is an iMC?
Allied IMC is precision manufactured for economical protection and long lasting value for the electrical raceway system. Manufactured from premium, work hardened steel combining electrical and mechanical performance with ductility. Allied IMC is resistant to impact and is easy to cut, bend and join for smooth, continuous raceways. Allied IMC is as strong, lighter in weight, and less expensive than Rigid. In fact, it can save you as much as 30% in overall costs. Intermediate Metal Conduit, covered by Article 342 in the National Electrical Code (NEC), is recognized as an equipment grounding conductor in Article 250 of the NEC and also provides excellent shielding from electromagnetic fields.
What is IMC code?
Codes & Standards Compliance. IMC is covered by Article 342 of the National Electric Code (NEC). It can be installed in all occupancies and locations, including Class I, Division I hazardous locations. Allied IMC is listed to Underwriters Laboratories Safety Standard UL 1242 and meets ANSI C80.6.
What is EMI shielding?
Allied IMC is very effective in reducing the effects of electromagnetic fields on encased power distribution circuits, shielding computers and other sensitive electronic equipment from the effects of electromagnetic interference. For more information, visit GEMI (Grounding and Electro-Magnetic Interference) software analysis program.
What is the NEC article for intermediate metal conduit?
In fact, it can save you as much as 30% in overall costs. Intermediate Metal Conduit, covered by Article 342 in the National Electrical Code (NEC), is recognized as an equipment grounding conductor in Article 250 of the NEC and also provides excellent shielding from electromagnetic fields.
What is the color of Allied IMC?
Even sizes are color-coded orange, 1/2 trade sizes are yellow, and 1/4 trade sizes are green.
Is Allied IMC the same as Rigid?
Allied IMC has a larger internal diameter than RIGID conduit to allow for easier fishing and wire-pulling. Allied IMC is also more “rigid” than RIGID to provide superior wiring protection in many applications. The National Electrical Code recognizes Allied IMC for the same uses as RIGID, including all hazardous location (classified) applications.
What is an IMC?
A LIGHTER WIRING SOLUTION WITH STRONG PROTECTION. IMC is manufactured as a cross between EMT and rigid metal conduit (RMC). A slightly thinner gauge than RMC, IMC is light but strong. It has the same electric-resistance welded tube-making process as EMT, but it is threaded like RMC, so the same couplings can be used for both.
Why is IMC bigger?
Because IMC is made of less steel, it has a larger inside diameter — allowing for easier wire pulling.
What is a conduit body?
Also known as conduit bodies, these ports provide access to wire and cable inside metal conduit for pulling, splicing, and maintenance. They are also used to change the direction of a run.
How do compression female straight connectors work?
Compression female straight connectors join two pieces of unthreaded conduit. Push the conduit into the ends; tighten the compression rings to secure.
What is RSC conduit?
The RSC/RMC conduit is manufactured from high-strength steel, and welded by electric resistance welding process.It is zinc coated both inside and outside with hot dip galvanizing in such a way that metal-to-metal contact and galvanic protection against corrosion are provided. The exterior surface of the Conduit adopts a clear post-galvanizing coating to provide further protection against corrosion. The interior surface provides a smooth continuous raceway for easy wire pulling. The ductility characteristics of our conduits help for easy bending, cutting, and threading in the field.
What is RMC in electrical?
Rigid Steel/Metal Conduit (RSC/RMC) is a threaded raceway of circular cross section designed for the physical protection and routing of conductors and cables and for use as an equipment grounding conductor when installed with its integral or associated coupling and appropriate fittings.
How long is RMC?
The Rigid Steel/Metal Conduit (RSC/RMC) is produced in normal trade sizes from 1/2“ to 6” in standard lengths of 10 feet (3.05 m). The rigid conduit is threaded on both ends, with a coupling applied to one end and a by size color coded thread protector to the other end as per table.
What is RSC/RMC?
RSC/RMC with coatings that are not zinc may have some temperature limitations, which are typically noted in the manufacturer's label. Both types of conduit allow you to install wiring without running boards and provide additional protection to the electrical system. RSC/RMC costs more in comparison to IMC, which is often one ...
Is RSC or RMC stronger?
