The Litetouch OEM task sequence is designed to copy an entire deployment share to the local system and shutdown. Thus the next time you start the machine, it will boot into WinPE and start the Litetouch build process (User menus, install OS, etc.). Here is someone walking through the process: http://www.laurierhodes.info/?q=node/67
How does the litetouch OEM task sequence work with MDT templates?
The point to note is that the only active part of the MDT template is copying an existing Task Sequence (along with all of its applications and support files) to a local drive in preparation for cloning. When the LiteTouch OEM Task Sequence is used, it will copy an entire distribution share to the local disk of a reference machine.
What is the litetouch OEM template?
The LiteTouch OEM template is a default template distributed with MDT. The point to note is that the only active part of the MDT template is copying an existing Task Sequence (along with all of its applications and support files) to a local drive in preparation for cloning.
What is the “standard” MDT build task sequence?
This share will contain a standard MDT build Task Sequence along with the MDT LiteTouch OEM Task Sequence. With the example above, the “standard” MDT task sequence does little more than deploy a captured Operating System Image, however, driver sets would typically be included for supported hardware types as well.
What is the difference between Lite Touch and zero touch deployment?
For Lite Touch deployments, it is common to have two deployment shares: one for creating the reference images and one for deployment. For Zero Touch, it is common to have only the deployment share for creating reference images because Configuration Manager deploys the image in the production environment.
How to monitor LTI deployment?
Prior to deploying the reference computer (WDG-REF-01) with the LTI bootable media you created earlier in the process, enable monitoring of the LTI deployment process. You monitor the LTI deployment process in the Monitoring node in the deployment share. You enable monitoring on the Monitoring tab on the deployment share properties sheet. Later in the process, you will monitor the LTI deployment process.
How to update deployment share?
To update the deployment share in the Deployment Workbench. Click Start, and then point to All Programs. Point to Microsoft Deployment Toolkit, and then click Deployment Workbench. In the Deployment Workbench console tree, go to Deployment Workbench/Deployment Shares.
What is MDT 2013?
Microsoft Deployment Toolkit (MDT) 2013 provides technology for deploying Windows operating systems, and Microsoft Office. This guide helps you quickly evaluate MDT 2013 by providing condensed, step-by-step instructions for using it to install the Windows 8.1 operating system through Lite Touch Installation (LTI) using bootable media (DVD or USB flash drive). This guide demonstrates how to perform the New Computer deployment scenario using an MDT 2013 deployment share. The New Computer deployment scenario covers the deployment of Windows 8.1 to a new computer. This scenario assumes that there is no user data or profile to preserve.
What is a WDG-REF-01?
Start the reference computer (WDG-REF-01) with the LTI bootable media you created earlier in the process. The LTI bootable media starts Windows PE on the reference computer and initiates deployment. At the end of the MDT deployment process, Windows 8.1 is deployed on the reference computer.
How to deploy a captured image to a target computer?
To deploy the captured image of the reference computer to the target computer, add the captured image to the list of operating systems in the Operating Systems node in the Deployment Workbench. The Import Operating System Wizard copies the operating system files to the deployment_share Operating Systems operating_system folder (where deployment_share is the deployment share folder created earlier in the process and operating_system is the name of the operating system added to the deployment share).
Where to create MDT task sequences?
Create MDT task sequences in the Task Sequences node in the Deployment Workbench using the New Task Sequence Wizard. MDT includes the Standard Client Task Sequence template, which you can use to deploy the target operating system to the reference computer (WDG-REF-01).
How to deploy MDT-CLI-01?
When you have captured an image of the reference computer (MDT-REF-01), deploy it to the target computer (MDT-CLI-01). You import the captured image into the Deployment Workbench using the Import Operating System Wizard. Then, you create a task sequence to deploy the captured image to the target computer.
How to use PowerShell in MDT?
The easiest way to find out how to use PowerShell in MDT is to use the Deployment Workbench to perform an operation and at the end of that task , click View Script. That will give you the PowerShell command.
Why is MDT important?
MDT is one of the most important tools available to IT professionals today. In addition to reducing deployment time and standardizing desktop and server images, MDT enables you to more easily manage security and ongoing configurations.
What is MDT support?
MDT supports the deployment of Windows 11 , as well as Windows 7, Windows 8.1, Windows 10, and Windows Server. It also includes support for zero-touch installation (ZTI) with Microsoft Endpoint Configuration Manager.
What is MDT file?
The file can be a standard .exe file with command-line switches for an unattended install, a Microsoft Windows Installer (MSI) package, a batch file, or a VBScript. In fact, it can be just about anything that can be executed unattended.
What is LTI in MDT?
Many features in MDT support Lite Touch Installation (LTI) for Windows 10. An LTI deployment strategy requires very little infrastructure or user interaction, and can be used to deploy an operating system from a network share or from a physical media, such as a USB flash drive or disc.
What is Windows Update?
Windows Update. Connects to a WSUS server and updates the machine.
What is boot image?
Boot images are the Windows Preinstallation Environment (Windows PE) images that are used to start the deployment. They can be started from a CD or DVD, an ISO file, a USB device, or over the network using a Pre-Boot Execution Environment (PXE) server. The boot images connect to the deployment share on the server and start the deployment.
What is Catapult Systems?
Catapult Systems — The Premier IT Consulting Company
Why does Catapult use cookies?
Catapult uses cookies to enhance your experience, to display customized content in accordance with your browser settings, and to help us better understand how you use our website. By continuing to browse or closing this banner, you indicate your agreement. To learn more about the cookies we use and to set your own preferences, see our Privacy and Cookie Policy.
How to restart Lite Touch?
The appropriate action is to either click “Finish” or reboot into the appropriate OS . You can also hit F8 at this point and format the drive and then restart or manually kick off the Lite Touch process again.
Does WinPE run LTICleanup?
Do this for both the x86 and x64 unattend.xml files to ensure this process works on both platforms. Now every time WinPE loads, it will first run LTICleanup, then it will launch the wizard.
LiteTouch OEM
Microsoft’s Deployment Toolkit provides the “LiteTouch OEM” Task Sequence as the MDT method of deploying a cloned installation of Windows. When MDT 2013 is installed (standalone) and a new Task Sequence is being created,
Create Installation Media
With this example, I’m going to create USB “Installation Media” for a standard Task Sequence and preparing a drive for OEM cloning.
How to create a new task sequence in Deployment Workbench?
Create a new task sequence in the Deployment Workbench, go the control folder, and copy the content of the task sequence folder you want to copy in to the new task sequence folder . Example: You have an old task sequence with an ID of REFW81X64-001, and you have created a new task sequence with an ID of REFW81X64-002. To have REFW81X64-002 being a duplicate of REFW81X64-001, simply copy the content of the REFW81X64-001 folder to REFW81X64-002.
How does copying a task sequence in MDT Lite Touch work?
When you copy a task sequence in MDT Lite Touch within the same deployment share, using the Deployment Workbench, you only get a link to the original task sequence.
What is manual option?
The manual option, copying a task sequence via the file system.
Can you copy a task sequence with a different name?
Note: Copying between deployment share will fail if an object with the same name already exist, but if you copy a task sequence with a different name, but the same task sequence ID, deployment workbench will simply replace the existing task sequence without any questions.
Can you copy a sequence in MDT Lite Touch?
When you copy a task sequence in MDT Lite Touch within the same deployment share, using the Deployment Workbench, you only get a link to the original task sequence. This means of you if you change the copied task sequence, you will also change the source task sequence.
Can you remove Silverlight from a test sequence?
Modifying the copied task sequence in the test folder, like removing the Silverlight app, will also remove Silverlight from the source task sequence.
Can you copy a task sequence ID?
Copying task sequences between deployment shares with the same name is prevented, copying with the same Task Sequence ID is not.
