Components of an Electric Motor
- Rotor. In an electric motor, the moving part is the rotor, which rotates the shaft to deliver mechanical power.
- Bearings. The rotor is supported by bearings, which allow the rotor to rotate on its axis. The bearings are in turn...
- Stator of an Electric Motor. The stator is the stationary part of the electromagnetic circuit of the motor and...
What are the major components of an electric motor?
What are the 7 parts of electric motor?
- A power supply – mostly DC for a simple motor.
- Field Magnet – could be a permanent magnet or an electromagnet.
- An Armature or rotor.
- Commutator.
- Brushes.
- Axle.
What are the parts and its function of electric motor?
What are the functions of the various parts of an electric motor?
- Stator: produces a rotating magnetic field in the air gap
- Rotor: The flux produced in the stator travels through the air gap and get linked to the rotor conductor. ...
- Cooling fans: The heat loss takes place in the stator and rotor on account of iron & copper loss. ...
Which is the non moving part of an electric motor?
There are no moving parts - no motors, no propellers, no gears and no drive shaft. Instead, a superconducting magnet, more efficient and powerful than conventional magnets, exerts a magnetic force ...
What are the basic parts of a motor?
Motor components are classified into five main portions (1) to (5) as Fig. 1.2 shows. Fig. 1.2 Motor components. (1) Rotor. Rotating part. (2) Bearing. Supporting part of the rotating shaft of the rotor. (3) Stator. Part generating force used to rotate the rotor. (4) Bracket or end plate.
What are the 6 parts of an electric motor?
Six Key Components That Make Up Your Industrial Electric Motor1) The Rotor. The rotor is the moving part of your electric motor. ... 3) The Bearings. ... 4) The Windings. ... 5) The Air Gap. ... 6) The Commutator. ... What Do All of These Components Have in Common?
What are the 7 parts of electric motor?
What is Electric motor ?Stator Coil.Rotor Coil.Main Shaft.Brush.Bearing.Drive Pulley.Motor Housing.
What are the 5 parts of an electric motor?
Different Parts of an Electric Motor and Their FunctionA power supply – mostly DC for a simple motor.Field Magnet – could be a permanent magnet or an electromagnet.An Armature or rotor.Commutator.Brushes.Axle.
What are main parts of motor?
Electric motor designs can vary quite a lot, though in general they have three main parts: a rotor, a stator and a commutator. These three parts use the attractive and repulsive forces of electromagnetism, causing the motor to spin continually as long as it receives a steady flow of electric current.
How does a Class 10 electric motor work?
Working Principle of Electric Motor The electric motor works on the principle that when a coil is placed in the magnetic field and the current passes through it resulting in rotation of the coil.
What is a electric motor Class 10?
Electric motor is a device that converts electrical energy to mechanical energy. Parts of a Electric Motor. Insulated Copper wire: A rectangular coil of wire ABCD. Magnet Poles: A magnet as placed above ie North Pole and South Pole.
What are the 4 parts of a motor circuit?
The Basic Parts of an Electric Circuit Every electric circuit, regardless of where it is or how large or small it is, has four basic parts: an energy source (AC or DC), a conductor (wire), an electrical load (device), and at least one controller (switch).
What are the parts of electric motor and generator?
An AC Motor/Generator Consists of 4 Main Parts: A shaft-mounted wire wound armature (rotor) A field of magnets that induce electrical energy stacked side-by-side in a housing (stator) Slip rings that carry the AC current to/from the armature.
What are the three basic parts of an electric?
An energy source – like a battery or mains power. An energy receiver – like a lightbulb. An energy pathway – like a wire. A wire helps to direct the electrons around the device.
What are the 2 parts of electric motor?
An electric motor consists of two major parts, the rotor and stator (see Figure 5).
How do electric motor works?
How do motors work? Electric motors work by converting electrical energy to mechanical energy in order to create motion. Force is generated within the motor through the interaction between a magnetic field and winding alternating (AC) or direct (DC) current.
What are the parts of electric motor and generator?
An AC Motor/Generator Consists of 4 Main Parts: A shaft-mounted wire wound armature (rotor) A field of magnets that induce electrical energy stacked side-by-side in a housing (stator) Slip rings that carry the AC current to/from the armature.
What is an electric motor name five main parts of a DC motor?
These components are: a stator, a rotor, a yoke, poles, armature windings, field windings, commutator, and brushes.
What are the main parts of 3 phase induction motor?
The motors consist of three main components – the stator, the rotor, and the enclosure. The stator consists of a series of alloy steel laminations around which are wound with wire to form induction coils, one coil for each phase of the electrical power source.
Which device converts mechanical work to electrical energy?
Generator is the device that converts mechanical work to electrical energy.
What is meant by electric motor?
An electric motor is used to convert electrical energy into mechanical energy.
What is the main function of armature core?
Armature core helps to hold the armature coil in place and provides mechanical support.
Give some examples where electric motor is used.
The electric motor is used in: Drills Water Pumps Hard Disc Drives Washing Machines Industrial Equipment
What are the parts of a motor?
Motor Basics. No matter the type of motor, there are three basic parts: a stator, a commutator, and a rotor. Together they use electromagnetism to cause the motor to spin. As long as the motor receives steady current, the motor works.
What is the magnetic field around a motor?
Taking the wire and coiling it around a rod with electricity generates a magnetic field. The magnetic field around the rod has two poles: north and south.
How does an electric motor stator work?
The electric motor stator stays stationary during the rotation. Usually, the stator has a row of magnets. These magnets have a casing that often looks like a drum. The rotor is inserted in the stator. Usually, the rotor consists of copper wire in a coil. The coil is around the spinning axle.
What is the ring at the end of a coil called?
At the end of the coil is a metal ring called the commutator. This piece reverses the current between the rotor and the battery. This keeps the axle spinning in a single direction. By reversing the magnet’s polarity, the rotor continues spinning through repulsion and attraction.
What are brushes made of?
Other Components. Additionally, the brushes can be made of graphite. Their role is to send an electric current to the motor’s commutator. The terminals send current to spin the rotor. They are typically located where the motor and battery attached.
Why do magnets spin?
With basic magnetism like poles repel each other. Therefore, opposite poles attract each other. By surrounding the rod with numerous magnets, the rod starts to spin. What causes the spinning? The rod moving between repulsive and attractive forces at the poles.
What are the parts of a motor?
A simple motor has the following parts: 1 A power supply – mostly DC for a simple motor 2 Field Magnet – could be a permanent magnet or an electromagnet 3 An Armature or rotor 4 Commutator 5 Brushes 6 Axle
What Is The Working Principle of An Electric Motor?
The working of an electric motor is based on the fact that a current carrying conductor produces a magnetic field around it. To better understand, imagine the following situation.
What is the commutator in a motor?
Commutator: It is the rotating interface of the armature coil with a stationary circuit. Field Magnet: The magnetic field helps to produce a torque on the rotating armature coil by virtue of Fleming’s left-hand rule. Armature Core: Holds the armature coil in place and provides mechanical support. Armature Coil: It helps the motor to run.
Why does an electric loop move?
Once electricity flows through your simple circuit, you will notice that your loop “moves”. So why does this happen? The magnetic field of the magnets interferes with that produced due to electric current flowing in the conductor. Since the loop has become a magnet, one side of it will be attracted to the north pole of the magnet and the other to the south pole. This causes the loop to continuously rotate. This is the principle of working of electric motor.
What is a field magnet?
Field Magnet – could be a permanent magnet or an electromagnet. An Armature or rotor. Commutator. Brushes. Axle. Power Source: A simple motor usually has a DC power source. It supplies power to the motor armature or field coils. Commutator: It is the rotating interface of the armature coil with a stationary circuit.
How to make a battery loop?
Take two bar magnets and keep the poles facing each other with a small space in between. Now, take a small length of a conducting wire and make a loop. Keep this loop in between the space between the magnets such that it is still within the sphere of influence of the magnets. Now for the last bit. Connect the ends of the loop to battery terminals.
How efficient is an electric motor?
Electric motors are used in a variety of applications. Some of them are listed below. You can expect the efficiency of a functioning motor to be around 70 – 85% as the remaining energy is wasted in heat production and sounds emitted.
What is Electric motor ?
Quoted from wikipedia, electric motor is a tool that serves to convert electrical energy into motion energy. These tools include dynamic power tools as they produce motion. The working principle of electric motors is to utilize magnetic pull force.
What are some examples of electric motors?
While in general, electric motors will be very easy to meet in everyday life. Examples are fans, water pumps, washing machines and blenders.
Why is the rotor dynamic?
Why is it dynamic? Because the coil is attached with the main shaft or main axle of the motor that will rotate.
Why do electric motors have two brushes?
In a simple electric motor should be equipped with two brushes. This brush will supply current and time for the coil rotor. In addition, this component is a popular cause that causes electric motor to die. The crust attached to the surface of the brush will cause the flow of the current to be inhibited. In addition, the condition of the brush is worn because it continues to be rubbed can also inhibit the flow of obstructed flow.
How many coils does a motor have?
On a motor generally has three stator coil. This depends on the capacity of the motor itself of course. The more the number of coils, the greater the magnetism generated. This will certainly affect the speed of the motor. But for simple electric motors, generally just complement the stator using a permanent magnet.
What is synchronous motor?
Synchronous motor, is an AC motor working at a fixed speed at a certain frequency system. This motor requires direct current (DC) for power generation and has a low initial torque, and therefore synchronous motors are suitable for low-load initial use, such as air compressors, frequency changes and motor generators. Synchronous motors are able to improve the system power factor, so it is often used on systems that use a lot of electricity.
What is AC motor?
An AC electric motor is a type of electric motor operating with an alternating current (AC, Alternating Current) voltage source. This AC electric motor can be distinguished by its resources as follows. Synchronous motor, is an AC motor working at a fixed speed at a certain frequency system.
2 Types of Electric Motors
The electric motors change electrical energy from stowed power or direct electrical connection into mechanical energy through a force. Here we have two types of electric motor that help in converting the energies into electric current, listed below:
Top 5 Uses of An Electric Motor
Electric motors are utilized in several applications, and a few of them are listed below; let's have a look:
Stator
Rotor
Commutator
Bearing and Shaft Assembly
Insulation Materials
Casing, Brushes, and Terminals
- The motor casing supports the stator and other motor components as well as protect the stator and rotor components from the external environment. Normally they are made up of aluminum. Carbon brushes are used to supply electricity to the rotor. It maintains contact with the commutator regardless of the speed of rotation. Contact pressure is maintai...
