How do you create an ArchiMate diagram?
Create a new diagram by selecting Diagram > New from the toolbar. In the New Diagram window, select ArchiMate Diagram and click Next. Enter Discharging Patients as diagram name and click OK to confirm diagram creation. This creates a blank ArchiMate Diagram.
What is the difference between ArchiMate and Togaf?
So What are the Differences? ArchiMate is a multi-purpose modeling language, whereas TOGAF is an Architecture Development Framework. TOGAF provides a Single Holistic meta-model with relationships, while ArchiMate provides a High-Level generic meta-model, as well as detailed per domain or layer meta-models.
How do you use ArchiMate tools?
4:541:00:33An Introduction to using ArchiMate in Enterprise Architect - YouTubeYouTubeStart of suggested clipEnd of suggested clipThe application layer allows us to document. Our application landscape. And understand interfacesMoreThe application layer allows us to document. Our application landscape. And understand interfaces and dependencies that exist between these applications. The technology layer allows us to catalog our
How many layers are defined in an ArchiMate diagram?
Three layersThree layers are defined within the ArchiMate core language as follows: 1. The Business Layer depicts business services offered to customers, which are realized in the organization by business processes performed by business actors.
What is ArchiMate used for?
ArchiMate (/ˈɑːrkɪmeɪt/ AR-ki-mayt; originally from Architecture-Animate) is an open and independent enterprise architecture modeling language to support the description, analysis and visualization of architecture within and across business domains in an unambiguous way.
Is Togaf exam difficult?
In spite of what you might hear from others, TOGAF Certification exam is not a complex exam. It is a complicated one which requires you to be careful in your approach and execution to clear it. In other words, it is a lot like Enterprise Architecture.
How do I open ArchiMate files?
How to Import/Export ArchiMate Model Exchange File?Select Project > Import > ArchiMate Model... from the application toolbar. To import ArchiMate model.Enter the filepath of the . xml file. ... Click Import. When finished, find the imported diagrams in Project Browser. ... To open a diagram, double click on its thumbnail.
Is ArchiMate free?
A free, perpetual Academic License is free to any academic organization wanting to use ArchiMate 2.1 entirely for academic (teaching and/or research) purposes.
How do I change the color in ArchiMate?
Changing ArchiMate shapes' colorRight click on the shape that you want to edit its color, and then select Styles and Formatting > Formats... from the popup menu. To format a shape.This shows the Formats window. ... And edit the background under the Background tab. ... Click OK to confirm and return to diagram.
What are the most common cross layer relationships in ArchiMate?
ArchiMate Cross Layer RelationshipsTechnology Layer.Business Layer.Application Layer.
Which of the following are the layers defined within the ArchiMate core language?
ArchiMate defines three layers – Business, Application, and Technology – based on specializations of the core concepts .
What is the difference between Togaf and Zachman framework?
A key distinction between TOGAF and Zachman is that the latter does not provide any implementation guidelines for actually creating architectural artifacts. Instead, it prioritizes creating awareness and providing viewers with a holistic overview of perspectives and relationships across an enterprise.
What is the best enterprise architecture framework?
Top 10 Enterprise Architecture FrameworksTOGAF's ADM.Zachman.Gartner's Enterprise Architecture Method.Federal Enterprise Architecture (FEAF)Dept of Defence Architecture Framework (DoDAF)Australian Government AGA.SABSA – Enterprise Security Architecture.Business Architecture Body of Knowledge (BizBoK)More items...
What is the difference between cobit and Togaf?
COBIT is a framework that is focused more on creating an enterprise-wide IT governance system that implements various controls for security. In contrast, TOGAF is used to create an information architecture for the company to incorporate business and IT goals in a streamlined fashion.
What is Togaf 9 certified?
TOGAF 9 Certified: This certification is for professionals with a deeper understanding of the TOGAF 9 standard and who can analyze and apply their knowledge in the development of an enterprise architecture. You must pass Part 1 and Part 2 tests to earn this credential.
What is Archimate model?
In a time when many enterprises are undergoing rapid change, ArchiMate models help stakeholders design, assess and communicate those changes within and between architecture domains, as well as examine the potential consequences and impact of decisions throughout an organization.
What is the Archimate specification?
The ArchiMate Specification is a modeling language that enables Enterprise Architects to describe, analyze and visualize relationships among architecture domains using easy to understand visuals representations. It also helps enterprise architects to:
What is Archimate language?
The ArchiMate language consists of the ArchiMate core language, which includes the Business, Application, and Technology Layers, along with elements to model the strategy and motivation underlying an architecture, as well as its implementation and migration.
Why is Archimate a layered view?
It is what ArchiMate makes an Enterprise Architecture language in the first place, because you can model all these different aspects in a single coherent model. A layered view provides a natural way to look at service-oriented models. The higher layers use services that are provided by the lower layers.
What is Archimate Implementation and Migration?
The ArchiMate Implementation and Migration elements enable the modeling of project portfolio management, gap analysis and transition and migration planning.
What are the business, application, and technology layers?
The Business, Application, and Technology Layers support the description of the Business, Information Systems, and Technology Architecture domains defined by the TOGAF framework, as well as their interrelationships.
What is the implementation and migration element of Archimate?
The implementation and migration elements of the ArchiMate language support the implementation and migration of architectures through the Opportunities and Solutions, Migration Planning, and Implementation Governance phases of the TOGAF ADM.
Why ArchiMate?
Organizations try to connect their models, to gain insight in the way the enterprise works from many different perspectives. Typically, models become more high-level, focusing on the essence of the organization. These developments have led to the development of the ArchiMate language, which allows high-level modeling within a domain, but allows modeling the relations between domains.
What is Archimate Implementation and Migration?
The ArchiMate Implementation and Migration elements enable the modeling of project portfolio management, gap analysis and transition and migration planning.
What is the full Archimate language?
The full ArchiMate language adds several layers and an aspect to the core framework. The physical elements are added to the Technology layer for modeling physical facilities and equipment, distribution networks, and materials. Besides, an additional motivation aspect and the implementation and migration elements are added. The resulting full ArchiMate framework is the figure below.
What are the benefits of Archimate?
The main benefits of ArchiMate for modeling your enterprise architectures are: It is an international, vendor-independent standard of The Open Group, liberating you from the lock-in of vendor-specific tools and frameworks. There is active support from the ArchiMate Forum of The Open Group.
What is layered view?
A layered view provides a natural way to look at service-oriented models. The higher layers use services that are provided by the lower layers. ArchiMate distinguishes three main (Core) layers:
What are the elements of a strategic model?
Elements for modeling the enterprise at a strategic level, such as capability, resource, and outcome.
What are the three aspects of enterprise architecture?
In each layer, three aspects are considered: active elements that exhibit behavior ( e.g. Process and Function), an internal structure and elements that define use or communicate information.
What is Archimate modeling?
ArchiMate ( / ˈɑːrkɪmeɪt / AR-ki-mayt; originally from Archi tecture-Ani mate) is an open and independent enterprise architecture modeling language to support the description, analysis and visualization of architecture within and across business domains in an unambiguous way.
What is the Archimate framework?
The main concepts and relationships of the ArchiMate language can be seen as a framework, the so-called Archimate Framework: It divides the enterprise architecture into a business, application and technology layer. In each layer, three aspects are considered: active elements, an internal structure and elements that define use or communicate information .
What is Archimate certification?
The Open Group has a certification program for ArchiMate users, software tools and courses. ArchiMate distinguishes itself from other languages such as Unified Modeling Language (UML) and Business Process Modeling and Notation (BPMN) by its enterprise modelling scope.
What are the three elements of the Archimate strategy layer?
Strategy Layer adds three elements: Resource, Capability and Course of Action . These elements help to incorporate strategic dimension to the ArchiMate language by allowing it to depict the usage of resources and capabilities in order to achieve some strategic goals.
When was Archimate 3.0.1 released?
In June 2016, the Open Group released version 3.0 of the ArchiMate Specification. The latest update of the Archimate is 3.0.1 that came out in August 2017.
How many layers are there in Archimate?
The main concepts and elements of the ArchiMate language are being presented as ArchiMate Core Framework. It consists of three layers and three aspects. This creates a matrix of combinations. Every layer has its Passive structure, Behavior and Active structure aspects.
Where was Archimate developed?
History. ArchiMate is partly based on the IEEE 1471 standard. It was developed in the Netherlands by a project team from the Telematica Instituut in cooperation with several Dutch partners from government, industry and academia.
What is Archimate notation?
Introduction. ArchiMate is very powerful notation, it provides many elements (concepts) divided into layers and aspects (figure 1 below). There can be lots of diagram types to be used within each layer and aspect. However, most of the cases can be modelled with only a small set of diagram types, which can be created with a subset ...
What is the goal view in Archimate?
The Goals View, which is composed with ArchiMate Motivation -elements, can be used as a starting point for each and every development case. Then, depending on the case, modelling can continue e.g. to 1) strategy modelling, 2) business modelling or 3) behavior and structure modelling (the architecture building blocks), or any combination of these.
What is Archimate 3.x?
Latest ArchiMate version 3.x provides catalog of viewpoints ( link) with descriptions and elements to be used within each viewpoint. Earlier ArchiMate version 2.x provided viewpoints ( link) with example diagrams, which were quite useful (but not very practical) for newbies to get the idea how modelling can support the development. These diagram types introduced here can form the basic foundation of the architecture landscape: 1) Goals View (Vision), 2) Layered View (Overview) and 3) Interaction Views (Integration). These diagram types (and variations of them) can be modeled per each development target. This continuously adds new content to the architecture repository, as new development targets created or existing ones are modified.
What are the different types of diagrams?
The most useful diagram types are as follows: 1. Motivation View – to define the value and meaning of the development target (with ArchiMate Motivation elements). 2. Layered View – to define all the relevant elements into one overall view (with elements from different layers and aspects) 3. Interaction View – to illustrate information flows between ...
What are the three motivation layers of Archimate?
The questions “TO WHOM?” “WHY?” and “WHAT?” can be analyzed with ArchiMate Motivation-layer concepts as follows: Stakeholder, Driver and Assesment, and Goal, Outcome, Principle and Requirement -concepts.
Why use diagram types for each case?
If same kind of diagram types are used with all the services, development targets etc., it keeps the architecture landscape coherent. If all of these diagram types (mentioned above) are used for each case, then the modelling approach is consistent and analogous. And finally, when using specific diagram types for each case for visualization, those cases can be easier to understand, shared and communicated among different stakeholders.
Can Archimate be used for a new service?
However, in practice, ArchiMate can be utilized by using only a subset of elements and only few diagram types to cover the most important aspects of each development target. This applies in most of the cases , no matter of the size or scale of the development target. It can be a new service or application, a business domain area etc.
What is an archimate viewpoint?
ArchiMate suggests a set of example viewpoints that can be used as starting points for modeling efforts. Each of these ArchiMate viewpoint comprises elements from different ArchiMate layers, addressing specific stakeholder concerns. Organizations are welcomed to apply any of these viewpoint examples in their architecture model, or to define their own ones.
What are the three main layers of Archimate?
ArchiMate basic viewpoints cover ArchiMate elements and concepts of the three main ArchiMate layers: Business, Application, and Technology . Listed below is a table of ArchiMate 3.1 example viewpoints, grouped into four categories that indicate which the direction and scope they cover:
What is viewpoint in Archimate?
In the ArchiMate language, a viewpoint is a relevant subset of ArchiMate elements and relationships, put together on a diagram in representing a particular part of an architecture.
What is information structure viewpoint?
The information structure viewpoint is works like a traditional information models commonly created in developing information system. The viewpoint shows the structure of the information used in the enterprise. It may also show how the information at the business level is represented at the application level in the form of the data structures used there, and how these are then mapped onto the underlying technology infrastructure.
Does Archimate constrain modeling?
It is important to note that the example viewpoints officially published in the ArchiMate specification should not constrain modeling activities. You should modify the example viewpoints or even to define your own viewpoints in addressing specific stakeholder concerns.
How to create an Archimate view?
Creating ArchiMate Views and Viewpoints is simple using Archi. Simply create a new ArchiMate View and set its Viewpoint to the one that is suitable for the target audience and stakeholders. Add concepts that are aligned to the given Viewpoint to create a unique perspective on your model.
What is Archimate modeling language?
The ArchiMate ® modelling language is an open and independent Enterprise Architecture standard that supports the description, analysis and visualisation of architecture within and across business domains. ArchiMate is one of the open standards hosted by The Open Group ® and is fully aligned with TOGAF ®. ArchiMate aids stakeholders in assessing the impact of design choices and changes.
What is a visualiser in a diagram?
The Visualiser displays the selected model element and all of its relationships with other model elements in a radial-tree graphic. It is the graphical equivalent of the Navigator. Selecting an element or relationship in the Model Tree, the Navigator or in a Diagram View will update the selection in the Visualiser. Drill in to see more connections.
Can I donate to Archi?
If you find Archi useful in your work and you’d like to help us maintain Archi, a donation would be most welcome, and we accept PayPal, or you could become a patron on Patreon. All development work and support is done for free. A small donation would be much appreciated!
Is Archi cross platform?
Archi is fully cross-platform as it is written in Java on the Eclipse Rich Client Platform. Therefore it works on Windows, macOS, and most Linux distros right out of the box. You don’t have to worry about sharing models across installations. A portable version and an installer version is available for Windows.
What is Archimate language?
The ArchiMate language may be implemented in software used for Enterprise Architecture modeling. For the purposes of this standard, the conformance requirements for implementations of the language given in this section apply. A conforming implementation:
Why is an enterprise architecture important?
An Enterprise Architecture is typically developed because key people have concerns that need to be addressed by the business and IT systems within an organization. Such people are commonly referred to as the “stakeholders” of the Enterprise Architecture. The role of the architect is to address these concerns by identifying and refining the motivation and strategy expressed by stakeholders, developing an architecture, and creating views of the architecture that show how it addresses and balances stakeholder concerns. Without an Enterprise Architecture, it is unlikely that all concerns and requirements are considered and addressed.
Is Archimate a trademark?
ArchiMate is a registered trademark of The Open Group.
What Is Archimate?
TOGAF Adm and Archimate
- The ArchiMate language consists of the ArchiMate core language, which includes the Business, Application, and Technology Layers, along with elements to model the strategy and motivation underlying an architecture, as well as its implementation and migration. The Figure below shows a simplified mapping of how the ArchiMate language can be used in relation to the phases of the …
Why Archimate?
- As shown the Figure above, the main reasons for enterprise architect to adopt ArchiMate are as follows: 1. Capture stakeholder concerns 2. Address concerns by identifying and refining requirements 3. Create EA models 4. Create views of the model for stakeholders 4.1. show how concerns and requirements will be addressed 4.2. show trade-offs arising from conflicting conc…
Guideline For Using Archimate Diagram with TOGAF Adm
- Follow the steps in TOGAF ADM for each development phase, starting from Preliminary Phase
- Follow the input, techniques and outputs to be performed for enterprise architecture development for each of the phases in ADM.
- TOGAF ADM is a iterative process rather than linear and sequential steps and phases
- The deliverables developed in the previous phase(s) will typically be used as the input docum…
- Follow the steps in TOGAF ADM for each development phase, starting from Preliminary Phase
- Follow the input, techniques and outputs to be performed for enterprise architecture development for each of the phases in ADM.
- TOGAF ADM is a iterative process rather than linear and sequential steps and phases
- The deliverables developed in the previous phase(s) will typically be used as the input documentation of the follow phases, they might be related in parts the data or the entire documentation
CORE Layers
- A layered view provides a natural way to look at service-oriented models. The higher layers use services that are provided by the lower layers. ArchiMate distinguishes three main (Core) layers: 1. The Business layeroffers products and services to external customers, which are realized in the organization by business processes performed by business actors and roles. 2. The Application …
Motivation Extension
- The ArchiMate Motivation elements enable the modeling of stakeholders, drivers for change, business goals, principles and requirements.
Implementation and Migration Extension
- The ArchiMate Implementation and Migration elements enable the modeling of project portfolio management, gap analysis and transition and migration planning.
Archimate Examples
- ArchiMate example – All layers In the example ArchiMate model below, you can see the integration of the various ArchiMate layers. ArchiMate diagram example – Information Structure This example is comparable to the traditional information models created in the development of almost any information system. It shows the structure of the information used in the enterprise …
Why Archimate?
Benefits of Archimate
- The main benefits of ArchiMate for modeling your enterprise architectures are: 1. It is an international, vendor-independent standard of The Open Group, liberating you from the lock-in of vendor-specific tools and frameworks. There is active support from the ArchiMate Forum of The Open Group. 2. Its well-founded concepts and models provide precisio...
Latest Archimate 3 Specification
- The latest version of the language is the ArchiMate 3.0 Specification, which was published in June 2016. ArchiMate 3.0 is a major update to the standard, with many new concepts. New features included in Version 3.0 include: 1. Elements for modeling the enterprise at a strategic level, such as capability, resource, and outcome. 2. It also includes support to model the physical world of …
The Archimate CORE Framework
- The aspects and layers of the core, as defined by the business, application and technology elements, can be organized as a framework of nine cells, as illustrated in Figure below. The structure of the framework allows for modeling of the enterprise from different viewpoints, where the position within the cells highlights the concerns of the stakeholder. A stakeholder typically c…
The Archimate Full Framework
- The full ArchiMate language adds several layers and an aspect to the core framework. The physical elements are added to the Technology layer for modeling physical facilities and equipment, distribution networks, and materials. Besides, an additional motivation aspect and the implementation and migration elements are added. The resulting full ArchiMate framework is th…
CORE Layers
- A layered view provides a natural way to look at service-oriented models. The higher layers use services that are provided by the lower layers. ArchiMate distinguishes three main (Core) layers: 1. The Business layeroffers products and services to external customers, which are realized in the organization by business processes performed by business actors and roles. 2. The Application …
Motivation Extension
- The ArchiMate Motivation elements enable the modeling of stakeholders, drivers for change, business goals, principles and requirements.
Implementation and Migration Extension
- The ArchiMate Implementation and Migration elements enable the modeling of project portfolio management, gap analysis and transition and migration planning.
Related Links
Summary
ArchiMate is an open and independent enterprise architecture modeling language to support the description, analysis and visualization of architecture within and across business domains in an unambiguous way.
ArchiMate is a technical standard from The Open Group and is based on concepts from the now superseded IEEE 1471 standard. It is supported by vario…
Overview
ArchiMate offers a common language for describing the construction and operation of business processes, organizational structures, information flows, IT systems, and technical infrastructure. This insight helps the different stakeholders to design, assess, and communicate the consequences of decisions and changes within and between these business domains.
The main concepts and relationships of the ArchiMate language can be seen as a framework, th…
History
ArchiMate is partly based on the now superseded IEEE 1471 standard. It was developed in the Netherlands by a project team from the Telematica Instituut in cooperation with several Dutch partners from government, industry and academia. Among the partners were Ordina, Radboud Universiteit Nijmegen, the Leiden Institute for Advanced Computer Science (LIACS) and the Centrum Wiskunde & Informatica (CWI). Later, tests were performed in organizations such as AB…
ArchiMate Framework
The main concepts and elements of the ArchiMate language are being presented as ArchiMate Core Framework. It consists of three layers and three aspects. This creates a matrix of combinations. Every layer has its Passive structure, Behavior and Active structure aspects.
ArchiMate has a layered and service-oriented look on architectural models. Th…
ArchiMate Language
The ArchiMate language is formed as a top-level and is hierarchical. On the top, there is a model. A model is a collection of concepts. A concept can be either an element or a relationship. An element can be either of behavior type, structure, motivation or a so-called Composite Element (which means that it does not fit just one aspect of the framework, but two or more).
Viewpoints
The latest version of ArchiMate introduces Views and Viewpoints. They allow stakeholders to define specific conditions like concepts, analysis techniques, models, and visualizations – a viewpoint, from which the model should be perceived.
A view (or a view model) “is defined as a part of an Architecture Description that addresses a set of related concerns and is tailored for specific stakeholders”. In return, the stakeholders give the…
Benefits and pitfalls of ArchiMate
• Ensures consistency across all architecture models (business domains)
• Allows the stakeholders to be involved in design, to assess all the requirements and it works well as a communication tool
• Richness of the tool – core framework, motivation extension that enriches the core with reasons why and implementation and migration extension
Exchange file format
A standard model exchange file format has been developed for ArchiMate 2.1 and 3.0 models. This is an XML/XSD based file format, and is intended for exchange rather than a persistent file format.
